The Haglöf Postex Laser System is an advanced and versatile solution for individual positioning within coordinate systems in forest sample plots. Designed for forest inventories, environmental monitoring, scientific research, and forestry management, it enables efficient and highly accurate field data collection using both laser and ultrasonic technology.
The Postex system is commonly used together with Haglöf Sweden DP II or Digitech Professional computer calipers and the Postex software application. Collected data can easily be exported as CSV files for visualization and analysis in platforms such as ArcGIS Online and other GIS systems.
The Postex Laser instrument integrates high-precision laser measurement with filter functionality and reliable ultrasonic technology, allowing users to select different height measurement methods depending on terrain conditions and field requirements. Its rugged construction and user-friendly interface make it ideal for demanding forest environments.
Data transfer can be performed via Bluetooth® or IR communication to portable devices, calipers, and field computers, maximizing productivity while reducing interruptions during positioning and measurement operations.
Perform sample plot inventories and obtain precise X,Y coordinates of individual trees for forestry studies and environmental monitoring applications.
The Postex system incorporates high-precision laser technology for fast and reliable distance measurements up to 700 meters. It can be used together with accessories such as monopods for improved measurement stability.
Vertex ultrasonic technology delivers excellent performance in dense forests and circular sample plots, enabling individual tree and seedling positioning even when there is no direct line of sight.
The Postex System offers multiple height measurement methods, allowing users to select the most suitable technique depending on environmental conditions and operational requirements.
The instrument displays angles in degrees, grads, and percentages, simplifying forest positioning and surveying operations with maximum precision.
| Model | Haglöf Postex Laser System |
| Measurement Technology | Laser and ultrasonic. |
| Laser Distance Range | 46 cm to 700 m depending on the target. |
| Laser Accuracy | 4 cm. |
| Laser Resolution | 0.1 m / ft (0.01 m in DME mode). |
| Ultrasonic Distance Range | 20 m / 60 ft. |
| Ultrasonic Accuracy | 1% or better. |
| Height Measurement | 0 to 999 m / ft. |
| Height Resolution | 0.1 m / ft. |
| Angle Range | -55° to 85°. |
| Angular Resolution | 0.1°. |
| Angular Accuracy | 0.1°. |
| Communication | Bluetooth® Class 2 and IR. |
| Data Format | NMEA or ASCII. |
| Display | 100 × 60 pixel graphic LCD. |
| Viewfinder | 1x LED sight. |
| Battery | Rechargeable 3.7V Li-Ion battery. |
| Approximate Runtime | Up to 9000 measurements. |
| Charging Time | Maximum 3.5 hours. |
| Operating Temperature | -20 °C to +45 °C. |
| Protection Rating | IP67, NEMA 6. |
| Laser Classification | Class 1 laser. |
| Instrument Dimensions | 93 × 63 × 72 mm. |
| Instrument Weight | 243 g. |
| Applications | Forest inventory, environmental monitoring, research, and tree positioning. |
